Product Details
Cable Clips
Installation Temperature
Minimum
Thickness
Uncoated
Coated
Operating Temperature
Minimum
Maximum
Material
Description
TyClip cable clips are used when a cable must be fixed neatly along a surface rather than just bundled with other cables. Tycab states that the clips are made from impact modified polyethylene for stress and creep resistance and supplied with assembled electrogalvanized nails to speed installation. They are best suited to electricians, builders, network installers and maintenance teams working on wall runs, ceiling drops, skirting routes and small cable installations where neatness, retention and installation speed are important.
| Product Code | Height mm |
Circle Path Diameter-mm |
Nail Size mm |
Remarks |
|---|---|---|---|---|
| Round | 7.5 | 1.6 X 16.5 | ||
| Flat | 12 X 6 | 1.6 X 16.5 | ||
| Oval | 15.2 X 11.4 | 1.7 X 18 | ||
| 4MM | 5.3 | 4 | 1.7 X 15 | |
| 5MM | 6 | 5 | 1.7 X 15 | |
| 6MM | 8 | 6 | 1.8 X 16 | |
| 7MM | 8.6 | 7 | 1.8 X 18 | |
| 8MM | 9.5 | 8 | 1.9 X 19 | |
| 9MM | 10.7 | 9 | 2.0 X 23 | |
| 10MM | 11.5 | 10 | 2.1 X 23 | |
| 12MM | 13.5 | 12 | 2.2 X 25 | |
| 14MM | 16.5 | 14 | 2.3 X 30 | |
| 16MM | 18 | 16 | 2.35 X 32 | |
| 18MM | 20.5 | 18 | 2.6 X 38 | |
| 20MM | 22.2 | 20 | 2.7 X 40 | |
| 25MM | 26.8 | 25 | 3.0 X 50 | |
| 32MM** | 33.8 | 32 | 3.3 X 55 | Double Nail Clips |
| 40MM** | 42.6 | 40 | 3.3 X 65 | Double Nail Clips |
